External Closed Square Ring 3/16 HD PL

XSC-113

GL Huyett

(click image to enlarge)
Quick Overview
    Interested in this item or want more information?
    Call Mon. through Fri. 8:00 AM - 5:00 PM PST
    Phone: 714-573-4083
    Email: sales@48ws.com

    Can't find what you want? Give us a call and we can help you find it.
    Details
    Attribute Name
    Value

    Weight (lbs.)
    0.0001
    Finish:
    Plain
    Free Diameter:
    .173
    Free Diameter Maximum:
    .173
    Free Diameter Minimum:
    .153
    Groove Depth:
    .006
    Groove Diameter:
    .176
    Groove Diameter Maximum:
    .179
    Groove Diameter Minimum:
    .176
    Groove Width:
    .029
    Groove Width Maximum:
    .031
    Groove Width Minimum:
    .027
    Inch or Metric:
    Inch
    Material:
    Spring Steel
    Shaft Diameter:
    .188
    Style:
    Wire
    Type:
    Square Ring - Closed Ext
    Wire Cross Section:
    .025
    Wire Cross Section Maximum:
    .027
    Wire Cross Section Minimum:
    .023

    All dimensions, specifications, and tolerances are for reference only and are subject to change without notice.

    Additional Information
    Manufacturer: GL Huyett
