Pre-fabricated geocomposite layer for use on sub-structure without waterproofing
Product DescriptionHydroduct® 200 is a strong preformed, 0.44 in. (11 mm) thick, geocomposite drainage sheet system. It is comprised of a hollow studded polystyrene core, covered on one side with a nonwoven, needle punched polypropylene filter fabric.
Use Hydroduct 200 has been specially developed to provide a simple and highly practical collector and deflector of unwanted ground water on foundation walls, retaining walls, bridges, tunnels and planters. Hydroduct 200 is acceptable for use with Preprufe®, however is not recommended for use over Bituthene® or Procor® waterproofing membranes. Hydroduct 200 has been designed to withstand ground pressures and the compaction forces of wet concrete to maintain a high water flow capacity. The drainage sheet must be connected into the site drainage system to minimize hydrostatic build-up and collect infiltrated water using Hydroduct Coil 600 or traditional perforated pipes wrapped and linked with the geotextile filter fabric to prevent clogging.
Safety, Storage and Handling InformationAll construction products must be handled properly. Material Safety Data Sheets (MSDS) are available at graceconstruction.com and users should acquaint themselves with this information. Carefully read detailed precaution statements on product labels and the MSDS before use.
Installation In vertical applications, Hydroduct 200 Drainage Composites can be applied to the substrate vertically or horizontally but, in either case, should extend from the perimeter discharge pipe to a point approximately 6 in. (150 mm) below the anticipated grade line.
