Aleph HYR-1003 – Ultraminiature Reed Switch

HYR-1003

Aleph USA

(click image to enlarge)
Quick Overview
    Interested in this item or want more information?
    Call Mon. through Fri. 8:00 AM - 5:00 PM PST
    Phone: 714-573-4083
    Email: sales@48ws.com

    Can't find what you want? Give us a call and we can help you find it.
    Details

    Specifications/Dimensions

    Item Value
    Contact Form 1A
    Contact Position1 C
    Contact Material Rhodium
    Max. Contact Rating 10W
    Max. Switching Voltage 100VDC
    Max. Switching current 0.5A
    Max. Initial Contact Resistance 200m ?
    Pull in Value (AT) 10-35
    Min. Drop out Value (AT) 4
    Min. Breakdown Voltage2 200VDC
    Max. Contact Capacitance 0.2pF
    Min. Insulation Resistance 1010?
    Typ. Resonant Frequency 5kHz
    Electrical Life (Resistive loads) 7 X 106 (5VDC, 10mA) 2 X 106 (12VDC, 250mA)
    Features Miniature switches With glass capsule length of 12mm. These switches use very little space. Applications include miniature reed relays, keyboards, etc.
    1. C: Center gap O: Off center gap
    2. Breakdown voltage specifications are based on Pull-In sensitivity of 25 AT or higher. Contact ALEPH for information for switches with less than 25 AT sensitivity.
    Additional Information
    Manufacturer: Aleph USA
