Aleph HYR-1555 – Form “C” Reed Switch

HYR-1555

Aleph USA

(click image to enlarge)
Quick Overview
    Interested in this item or want more information?
    Call Mon. through Fri. 8:00 AM - 5:00 PM PST
    Phone: 714-573-4083
    Email: sales@48ws.com

    Can't find what you want? Give us a call and we can help you find it.
    Details

    Specifications/Dimensions

    Item Value
    Contact Form 1C
    Contact Position1 O
    Contact Material Ruthenium3
    Max. Contact Rating 3W
    Max. Switching Voltage 100VDC
    Max. Switching current 0.25A
    Max. Initial Contact Resistance 200m O
    Pull in Value (AT) 15-50
    Min. Drop out Value (AT) 5
    Min. Breakdown Voltage2 200VDC
    Max. Contact Capacitance 0.8pF
    Min. Insulation Resistance 109 O
    Typ. Resonant Frequency 2.4kHz
    Electrical Life (Resistive loads) 108 (10mVDC, 10µA) 2 X 106 (12VDC, 250mA)
    Features Single pole, double throw
    1. C: Center gap O: Off center gap
    2. Breakdown voltage specifications are based on Pull-In sensitivity of 25 AT or higher. Contact ALEPH for information for switches with less than 25 AT sensitivity.
    3. Ruthenium Oxide over Rhodium.

    Additional Information
    Manufacturer: Aleph USA
