Aleph HYR-2003-2 – High Power Reed Switch

HYR-2003-2

Aleph USA

(click image to enlarge)
Quick Overview
    Interested in this item or want more information?
    Call Mon. through Fri. 8:00 AM - 5:00 PM PST
    Phone: 714-573-4083
    Email: sales@48ws.com

    Can't find what you want? Give us a call and we can help you find it.
    Details

    Specifications/Dimensions

    Item Value
    Contact Form 1A
    Contact Position1 C
    Contact Material Rhodium
    Max. Contact Rating 50W
    Max. Switching Voltage 200VDC/110VAC
    Max. Switching current 1.0A
    Max. Initial Contact Resistance 100m O
    Pull in Value (AT) 20-60
    Min. Drop out Value (AT) 8
    Min. Breakdown Voltage2 300VDC
    Max. Contact Capacitance 0.4pF
    Min. Insulation Resistance 109 O
    Typ. Resonant Frequency 2.5kHz
    Electrical Life (Resistive loads) 107 (10mV, 10mA) 2 X 104 (50VDC, 1A)
    Features High power
    1. C: Center gap O: Off center gap
    2. Breakdown voltage specifications are based on Pull-In sensitivity of 25 AT or higher. Contact ALEPH for information for switches with less than 25 AT sensitivity.

    Additional Information
    Manufacturer: Aleph USA
