Greenguard Insulation Board

GG60-LG

KingSpan

Insulation for High Load-Bearing Engineered Applications Requiring 60 psi Minimum Compressive Strength
(click image to enlarge)
Quick Overview
    GreenGuard GG60-LG XPS Insulation Board comprises closed–cell extruded polystyrene (XPS) with a minimum compressive strength of 60 psi. It has high water resistance and R–value of 5.0 per inch of thickness. It is available in a square edge board or a drainage channel board. Kingspan GreenGuard LG XPS Insulation Board is made of synthetic materials that are generally recognized as not providing a food source for insects, fungus, mold, or mildew. It should always be properly installed and stored. Kingspan GreenGuard GG60-LG XPS Insulation Board is HCFC free.
Interested in this item or want more information?
Call Mon. through Fri. 8:00 AM - 5:00 PM PST
Phone: 714-573-4083
Email: sales@48ws.com

Can't find what you want? Give us a call and we can help you find it.
Details
Property Test Method Result Nominal Thickness (in) 1 1/2, 2, 3 Nominal Board Width (ft) 2 Nominal Board Length (ft) 8 Edge Profile Square1 Property Type ASTM C 578 VII Compressive Strength, Min. (psi@ 10% deflection) ASTM D 1621 60 Water Absorption, Max. (% by volume) ASTM C 272 0.1 Density, Min. (lb/ft³) ASTM C 303 2.2 Water Vapor Permeance (perm) ASTM E 96(Dessicant Method) < 1.0 Service Temperature, Max (°F) 165 Thermal Thermal Resistance, R-value2 (°F.ft².hr / Btu per in thick) ASTM C 518 (@75°F Mean Temperature) 5.0 Thermal Conductivity, k-value (Btu.in / hr.ft².ºF) ASTM C 518 (@75°F Mean Temperature) 0.2 Fire & Smoke Flame Spread3 Smoke Developed3 ASTM E 84 / UL723 15 (Class A) 140
Additional Information
Manufacturer: KingSpan
